MS SQL integration

MS SQL is a database management system.

Windmill provides a framework to support MS SQL databases, either with native SQL scripts or through TypeScript for raw queries.

Integration between MS SQL and Windmill

Authentication methods​

Windmill supports multiple authentication methods for MS SQL Server:

  • Username/Password: Standard SQL Server authentication
  • Azure AD (Entra): OAuth-based authentication for Azure-hosted databases
  • Azure workload identity: the worker authenticates as its own managed identity on AKS, with no password stored in the resource
  • Windows Integrated Authentication: the worker authenticates as itself in Active Directory environments, with Kerberos on Linux workers and with Windows SSPI on Windows workers, where the identity is the Windows account the worker runs as

For detailed setup instructions, including Windows Integrated Authentication configuration on Linux and Windows workers, refer to the SQL Getting started section.


Azure workload identity for Azure SQL​

On AKS, workers can authenticate to Azure SQL as their own workload identity instead of with a password or a manually issued AAD token. The pod's projected service account token is exchanged with Microsoft Entra ID for a short-lived access token, so no credential is stored in the resource and none expires in it.

Setup​

  1. Give the worker a workload identity. Enable the OIDC issuer and the workload identity add-on on the cluster, create a user-assigned managed identity, and add a federated credential binding it to the worker's Kubernetes service account:
az identity federated-credential create \
--name windmill-worker \
--identity-name <managed-identity-name> \
--resource-group <resource-group> \
--issuer "$(az aks show -n <cluster> -g <resource-group> --query oidcIssuerProfile.issuerUrl -o tsv)" \
--subject "system:serviceaccount:<namespace>:<worker-service-account>" \
--audience api://AzureADTokenExchange

Annotate the service account with azure.workload.identity/client-id: <client-id> and label the worker pods with azure.workload.identity/use: "true". The webhook then injects AZURE_TENANT_ID, AZURE_CLIENT_ID, AZURE_FEDERATED_TOKEN_FILE and AZURE_AUTHORITY_HOST into the worker, which is where Windmill reads the identity from. Nothing about the identity is configured on the resource, so a worker reaching two databases as two different identities needs two worker groups.

  1. Create the database user. Connect to the database as an Entra administrator and map the managed identity:
CREATE USER [<managed-identity-name>] FROM EXTERNAL PROVIDER;
ALTER ROLE db_datareader ADD MEMBER [<managed-identity-name>];
  1. Create an ms_sql_server resource with ms_entraid as the password. That value is a sentinel rather than a real password: it tells the worker to authenticate as its workload identity. Leave user and aad_token empty.
{
"host": "myserver.database.windows.net",
"port": 1433,
"dbname": "mydb",
"password": "ms_entraid",
"encrypt": true,
"trust_cert": false
}

The job logs state Using Azure Workload Identity along with the client id whenever the sentinel takes effect. A resource whose password happens to be literally ms_entraid is treated the same way, so pick a different password if that ever collides.
